BAT Machine Co.
BAT Machine has a world-renowned reputation of making the best rifle receivers ever built. Their benchrest models have held or still hold almost all IBS and NBRSA records. The Ignitor (replacing the BT) and BTE actions incorporate all the knowledge learned from making benchrest actions and starting in 2011 we worked together to bring it to the tactical shooting world. Shoot the original Bat Tactical Action, winning matches since 2012.
Current inventory in stock and ready to build!
|
Bat Tactical Elite
|
Bat Igniter
|
|
|
|
The Bat Tactical Elite Action
The BAT Tactical Elite Action is the original Bat Tactical and predecessor to the TR putting into place ground-breaking improvements for tactical/field shooting. The BTE is a better and stronger extractor and ejector for faster and reliable ejection, a new body design for increased stiffness, the original bolt design that increased reliability in dirty field conditions. We do not use trigger hangers (that is for benchrest) and we use a flat bolt face. A bolt nose that requires a recess cut into the barrel/chamber is nothing more than a place for it to deposit and jam dirt and debris while shooting. This action is compatible AICS magazines and M5 bottom metals for feeding and functioning reasons.
Bolt to receiver clearance is 0.0025″, to allow for smooth operation in all environments. BTE's are fully salt bath nitrided to harden the receiver, and can be ran with no oil or grease.
Features standard on the Bat Tactical Elite:
Bolt to receiver clearance is 0.0025″, to allow for smooth operation in all environments. BTE's are fully salt bath nitrided to harden the receiver, and can be ran with no oil or grease.
Features standard on the Bat Tactical Elite:
- These actions have the LiFe Salt Bath Nitriding process done to the majority of the components.
- 20 MOA integral Picatinny rail.
- Integral recoil lug, full width and .25 thick.
- M-16 style extractor.
- Large anodized aluminum knob with 5/16-24 thread.
- Modular bolt.
New - Bat Igniter Action
|
|
|
The New BAT Ingiter is our next generation action. This is our field/hunting action that put into place ground breaking improvements for hunting/field shooting. It is just as strong and accurate as out BTE action with less material removed from the top strap of the receiver and a stronger picatinny rail. It does include the better and stronger extractor and ejector for faster and reliable ejection, the new body design for increased stiffness, the original bolt design that increased reliability in dirty field conditions. We do not use trigger hangers (that is for benchrest) and we use a flat bolt face. A bolt nose that requires a recess cut into the barrel/chamber is nothing more than a place for it to deposit and jam dirt and debris during field shooting. This action is compatible AICS magazines, M5 DBM and R700 BDL and ADL floorplates.
Bolt to receiver clearance is 0.0025″, to allow for smooth operation in all environments. The BT bolt is salt bath nitrided to (hardened) so it can be ran with no oil or grease. The action is Blued.
Features include:
Bolt to receiver clearance is 0.0025″, to allow for smooth operation in all environments. The BT bolt is salt bath nitrided to (hardened) so it can be ran with no oil or grease. The action is Blued.
Features include:
- Action body is made using hardened 4140 Chromoly Steel and blued.
- Includes integral recoil lug.
- The action top is drilled for 8*40 screws and has .125 pin hole to prevent rail movement.
- Modular bolt for lower cost bolt face changes.
- Bolt Face choices are .385 (223) .480 (308) and .55 (magnum)
- Has our proven .070 firing pin diameter for maximum accuracy and reliable ignition.
- Comes with a medium size aluminum knob. The handle has a 5/16x24.
- LiFe (Melonite) treated firing pin, bolt and shroud for extremely smooth bolt movement and low maintenance.
- Allows use of most Remington 700 SA components.
- Rght and Left hand and versions available now.
- Barrel tenon is 1.062 x 18 tpi Click here for print
- Weight; Bare action: 1 lb 14 oz – Pic rail 2 oz – 30mm low rings 3.4oz
Bat Bumblebee Aluminum Action
|
|
|
We are excited to offer the ultimate solution for all shooters that need a Light weight, Premium quality action!
The Bumblebee is designed to use 700 Short Action bottom metal and we can inlet your existing 700 SA stock or chassis to fit this flat bottom action.
Features include:
The Bumblebee is designed to use 700 Short Action bottom metal and we can inlet your existing 700 SA stock or chassis to fit this flat bottom action.
Features include:
- 11.4 oz lighter than our VR/TR action!
- The weight is 23.8 oz as configured in photos. You will find the weight to be very comparable to Titanium actions after you add for Picatinny rails, recoil lugs and the hardware required to mount them!
- 31%-42% stiffer than light weight steel actions and over 130 stiffer than round Titanium actions!
- Action body is made with a combination of Aluminum and hardened Steel to gain the best combination of light weight and strength .
- Integral 20 MOA picatinny rail comes standard this allows easy 100 yard zero and gains the maximum capability of your scope for the long shots. Also you can sleep at night knowing your bases won’t be coming loose.
- Multiple scope mounting positions to accommodate most all scope configurations and eye relief.
- Modular bolt for lower cost bolt face changes.
- Has our proven .070 firing pin diameter for maximum accuracy and reliable ignition.
- Comes with a medium size aluminum knob. The handle has a 5/16x24.
- LiFe (Melonite) treated firing pin, bolt and shroud for extremely smooth bolt movement and low maintenance.
- Extended extraction cam for smooth bolt opening.
- Allows use of most Remington 700 SA components
- Right and Left hand versions.
- Barrel tenon is 1.068 x 18 tpi. Click here for print
